Double Pole Miniature Circuit Breaker 70A

$50.16

Created with Sketch.
Eligible for FREE SHIPPING
Created with Sketch.
Usually ships within 24 hours
1

Request a Bulk Quote

Thank you for your quote request. We will be in touch.

SKU: 10113922
MFG: QO270CP

Description

"SQUARE D" MINIATURE CIRCUIT BREAKER

  • When breaker trips, the handle snaps to a mid-point position & red indicator identifies trip.
  • Plug-on design - easy to install - wire-terminals.
  • Features: VISI-TRIP trip indication.
  • Circuit Breaker Type: Standard
  • General Application: Provides overload and short circuit protection.
  • Type: QO
  • Wire Size: #8-2 AWG(Al/Cu)
  • Width: 1.5"
  • Height: 3.12"
  • Depth: 2.91"
  • Ampere Rating  70A
  • Voltage Rating: 120/240VAC
  • Mounting Type: Plug-On
  • Number of Poles: 2-Pole
  • Space Required: 2
  • Short Circuit Current Rating: 10kA
  • For Use With: QO Load Centers, NQOD Panelboards/Interiors and Speed-D switchboard distribution panels.
  • HACR Rated: Yes
  • Terminal Type: Box Lugs
  • Special Packing: Bulk packaging
  • Approvals: UL Listed, CSA Certified

Specifications

MFR:
QO270CP
SKU:
10113922
UPC:
047569008955
Brand:
Square D
Length:
4
Width:
3
Height:
2
Weight:
1.0 lb
